Feed particle size：50~300mm
Capacity：40~510t/h
[Materials]：Widely used in industries such as metal and non-metallic mines, building materials, transportation, metallurgy, water conservancy, etc...
+8613897984610
7*24 hour service hotline
Product Brief Introduction
HGP series cone crusher is suitable for large and medium-sized sand, ore processing enterprises, used for ore, rock or rock base materials of secondary, tertiary or driver crushing. The crushing process is discharged from the breaking wall of the eccentric swing driven by the eccentric sleeve and the lower part of the mortar wall. It has the advantages of high output, low use cost, exquisite structure, simple operation, less maintenance, wide application range and high use rate.
Main performance characteristics
Wide range of use.
Good grain shape.
Lower production cost.
Simple operation and maintenance.
The liner is finished and no filler is required for assembly.
Making the operation more intuitive.
Technical Parameters
| Model | Type of chamber | Feeding size(mm) | Adjusting range of discharge opening (mm) | Capacity(t/h) | Power (kw) | Dimension(mm |
| DG100 | coarse Type | 150 | 16～40 | 60～125 | 75～90 | 1700×1600×2650 |
| Medium Type | 100 | 14～35 | 50～100 | |||
| Fine Type | 60 | 10～30 | 40～90 | |||
| DG200 | coarse Type | 180 | 16～50 | 120～230 | 132～160 | 2100×1800×3100 |
| Medium Type | 140 | 14～40 | 100～210 | |||
| Fine Type | 70 | 10～30 | 80～180 | |||
| DG300 | coarse Type | 200 | 20～60 | 200～400 | 220～250 | 2600×2200×3800 |
| Medium Type | 140 | 16～45 | 160～350 | |||
| Fine Type | 90 | 12～35 | 130～280 | |||
| DG400 | coarse Type | 230 | 20～65 | 260～500 | 280～315 | 2800×2400×3900 |
| Medium Type | 160 | 15～50 | 200～400 | |||
| Fine Type | 100 | 12～40 | 160～350 | |||
| DG500 | coarse Type | 250 | 20～70 | 350～650 | 315～400 | 2800×2400×3900 |
| Medium Type | 170 | 16～50 | 280～500 | |||
| Fine Type | 10 | 12～40 | 200～450 | |||
| DG650 | coarse Type | 300 | 20～75 | 400～750 | 450～500 | 3160×2600×4250 |
| Medium Type | 200 | 16～55 | 320～660 | |||
| Fine Type | 120 | 12～45 | 280～500 | |||
| DG800 | coarse Type | 350 | 20～75 | 450～880 | 560～6300 | 3350×2800×4450 |
| Medium Type | 260 | 16～55 | 360～750 | |||
| Fine Type | 160 | 12～45 | 300～690 |
